DESCRIPTION

Basic Info

Model NO.	ISO2531/EN545/EN598
Connection	Flange
Color	Blue
Usage	Pipeline Connection
Transport Package	Standard Export Package or as Per Your Requirement
Specification	different sizes available
Trademark	SYI
Origin	Shanxi
Production Capacity	1500tons/Month

Packaging & Delivery

Package size per unit product 50.00cm * 50.00cm * 50.00cm Gross weight per unit product 20.000kg

Product Description

Product Description:

SYI can supply Loosing Flanged Pipe Fittings PN10, PN16, PN25 drilling in accordance with ISO 7005-2/EN1092-2, from DN80 to DN600, with the coating of Zinc and Black Bitumen coating, Red/Blue Epoxy coating, or PU (polyurethane) coating.

Specifications:

Loosing Flange Pipe Fitting
Material:
BODY: Ductile iron grade 500-7/ 450-12 in accordance with ISO 1083 or 70-50-05/65- 45-12 with ASTM A536 GLAND: Ductile iron grade 500-7/ 450-10 in accordance with ISO 1083 or 70-50-05/65 -45- 12 with ASTM A536 GASKET: Rubber E.P.D.M./SBR/NR in accordance with EN 681.1 BOLTS AND NUTS: Carbon steel grade 6.8 with galvanization
Flange:
PN10/PN16/PN25 drillings in accordance with ISO 7005-2/EN 1092-2
Working Pressure:
16/25 Bar or 250/350 PSI
Fluid Temperature:
0°C-50°C, excluding frost
Coating:
Externall coatings: liquid epoxy resin painting epoxy applied by FBE according to customers' requirements	Internall coatings: liquid epoxy resin painting epoxy applied by FBE according to customers' requirements
Reference Rules:
Designed and tested in accordance with EN 14525, ANSI/AWWA C219 and EN 545
Use:
Loosing Flanged Fittings is on this kind of fittings can be freely rotated around the pipe axis before jointing,that is more convenient for installation
Note: The gaskets,bolts and nuts are supplied separately with the fittings usually

Company Profile:

About SYI Group Specialist in Municipal, Pipeline & Machinery Products & Services.

SYI Group Companies are capable of both manufacturing and trading service, who have served the society for 30 years with best Municipal, Pipeline and Machinery products.
SYI Pipeline Corporation - a Proud Member of SYI Group - manufactures a full range of Pipeline products and accessories like Pipes, Fittings, Universal Couplings, Flanged Adaptors, Quick Adaptors, Dismantling Joints, Clamps, Valves, and etc. SYI Foundry (Shanxi Yuansheng Casting & Forging Industrial) - the First Foundry of SYI Group - manufactures Manhole Covers, Gully Gratings, Surface Boxes, Tree Gratings, Bollards, Garden Benches, Cast Lamp Posts & Bases and all types of SYI/OEM municipal products and outdoor furnitures. SYI Forging Factory - an Outstanding Member of SYI Group - manufactures Flanges, Forged Rings, Forged Fittings, Lifting Anchors, Drop Forgings, Cold Forgings and other Free Forging and Die Forging products.
